| Model | AW- | 25RL2-250L | 25RL2-300L | ||||
| Heating Capacity | kW | 2.42 | 2.42 | ||||
| Consumen Power | kW | 0.62 | 0.62 | ||||
| COP | kW/kW | 3.88 | 3.88 | ||||
| Hot Water Volume | L/h | 52.00 | 52.00 | ||||
| Operation Range | ℃ | -7~43 | |||||
| Max.Outlet Water Temp. | ℃ | 75 | |||||
| Max. Power Input | kW | 2.93 | 2.93 | ||||
| Max. Running Current | A | 13.40 | 13.40 | ||||
| Power Supply | / | 220-240V~/50Hz | |||||
| Wi-Fi Function | / | YES | |||||
| Electric Heating | kW | 2 | |||||
| Water Connection | inch | G3/4"(female) | |||||
| Sound Pressure Level at 1m | dB(A) | ≤53 | |||||
| Gas Control | / | EEV | |||||
| Refrigerant | / | R134a | |||||
| Water Tank Type | / | Enamel | |||||
| Water Tank Volume | L | 250 | 300 | ||||
| Water Proof Level | / | IPX4 | |||||
| Net Dimensions(D×H) | mm | φ640×1802 | φ640×2020 | ||||
|
Test Condition:Ambient Temperature: (DB/WB) 20°C / 15°C；Water Temperature from 15°C to 55°C The Sound power level is tested by EN12102 |
|||||||
